Description
Overview
The EC65 sits in the mid-range of Volvo’s compact excavator lineup and is built for versatility across construction, utilities, landscaping, and agricultural work. Compared to the previous generation, it features increased engine power, stronger lifting capability, and improved swing performance, making it more productive in demanding conditions.
A major upgrade is the completely redesigned operator environment, with an 8-inch high-definition touchscreen, improved ergonomics, and enhanced controls—bringing features typically found in larger excavators down to the compact class.
Performance & Capabilities
The EC65 is engineered to deliver strong digging and lifting performance for its size:
- Around 4% more engine power than its predecessor
- Up to 9% increase in boom lifting force
- Improved swing torque and stability on slopes
- Double auxiliary hydraulic flow for running demanding attachments
These upgrades allow the machine to handle a wide range of tools such as breakers, augers, tiltrotators, and hydraulic thumbs with greater efficiency.
Key Specifications
Engine & Power
- Engine model: D2.6H
- Gross power: 46 kW (62 hp)
- Net power: 45 kW (60 hp)
- Rated speed: 2,200 rpm
Weight & Size
- Operating weight: 5,750 – 6,810 kg (≈ 12,680 – 15,020 lbs)
- Overall width: 2,000 mm
- Overall length: 5,840 mm
Hydraulics & Performance
- Main hydraulic flow: 120 L/min (32 gal/min)
- Breakout force: 37.7 kN
- Arm tear-out force: 28.2 kN
- Slew speed: 9.1 rpm
Working Capabilities
- Bucket capacity: 0.07 – 0.27 m³
- Travel speed: up to 4.4 km/h
- Boom swing angle: 80° left / 50° right
Fuel & Service
- Fuel tank: 120 litres (increased capacity)
- Extended service intervals (e.g. DPF cleaning up to 8,000 hours)
Operator Comfort & Technology
Volvo has heavily focused on operator experience in this model. The EC65 includes:
- 8″ touchscreen display with machine settings and camera views
- Bluetooth connectivity and in-cab storage features
- Redesigned suspended seat with adjustable armrests
- Improved joystick layout and dozer blade controls
These changes aim to reduce operator fatigue and improve productivity over long working hours.
Efficiency & Maintenance
The EC65 is built to maximise uptime and reduce running costs:
- Longer maintenance intervals than previous models
- Easy ground-level access to service points
- Larger fuel tank for longer working periods
- Integrated telematics (CareTrack) for machine monitoring
All of this helps contractors keep the machine working longer with less downtime.
